Fike FCP-300 - Point Programming For FIK-5880 or 5865 Modules

Point Programming
FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 101
.
9.5.3 Point Programming For FIK-5880 or 5865 Modules
To program the Model FIK-5880 or 5865 module points, do the following.
1. Enter the Installer Code.
2. Select 7 for Program Menu.
3. Press 4 to enter Point Menu.
Choices Type Selections
Function Selections
for each Type
Comments
Enter Point
Select Type UNUSED
B NOTIF NOTIF OUTPUT User also has Supervised/
Unsupervised option
CONTROL CIRCUIT
A NOTIF Same as B NOTIF
AUX_PWR CONSTANT Constant auxiliary power.
AUX RESET Resettable auxiliary power.
AUX DOOR Door holder auxiliary power.
AUX SYNC Power Sync
Select Type B SWITCH* MANUAL PULL Refer to comments column of
Table 9.5 for description of these options.
Latch or Non-latching feature only appears for
WATERFLOW, FIRE SUPERVISORY, FIRE
TAMPER, ZONE AUX1, ZONE AUX2, System AUX1,
System AUX2, ECS INPUT, ECS TAMPER, and ECS
SUPERVISORY.
WATERFLOW
FIRE SUPERVISORY
FIRE TAMPER
FIRE DRILL
SILENCE
RESET
P.A.S. ACK
ZONE AUX1
ZONE AUX2
System AUX1
System AUX2
MANUAL RELEASE
INTERLOCK
STATUS POINT
ECS INPUT User also has ECS Event Number 1-8 option for ECS
INPUT.
Only available when an FIK-NVCM is installed in the
System.
ECS TAMPER
ECS SUPERVISORY
A SWITCH* Same as B SWITCH
B DETECT* 2-WIRE SMOKE Used for Class B, 2-wire detectors.
4-WIRE SMOKE Used for Class B, 4-wire detectors.
CO 4-WIRE DET Used for Class B, 4-wire CO detectors.
CO 4-WIRE SUP DET Latching or Non-latching used for Class B, 4-wire CO
Supervisory detectors
A DETECT* 2-WIRE SMOKE Used for Class A, 2-wire detectors.
4-WIRE SMOKE Used for Class A, 4-wire detectors.
CO 4-WIRE DET Used for Class A, 4-wire CO detectors.
Select Zone/Group Group or Zone selection will appear depending on the
type selected.
Edit Name See “Editing Text Using the Built-In Programmer” on
page 206.
* Only applicable for 5895XL
Table 9.6 Menu choices for Internal/External Power Module
