FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 61
Section 6: Network Management
6.1 Network Diagnostics
6.1.1 Ping Panel
The Ping Panel Menu allows you to continually ping any panel programmed into the network. As the selected panel is being pinged, the
Ping Panel screen will display the reply time, minimum and maximum reply times, and sent and received counters.
1. Enter the Installer Code. The panel will automatically access the Main Menu.
2. Select 5 for the Network Diagnostics.
3. Press 1 to enter the Ping Panel Menu.
4. Press the up or down arrow key to select the Network Panel ID. Press ENTER to access the Ping panel.
6.1.2 Data Network Status
The Data Network Status screen will display statistics that are indicators of Network performance.
1. Enter the Installer Code. The panel will automatically access the Main Menu.
2. Select 5 for Network Diagnostics.
3. Press 2 to enter the Data Network Status Menu.
6.1.3 Voice Network Status
The Voice Network Status screen will display statistics that are indicators of the Network performance.
1. Enter the Installer Code. The panel will automatically access the Main Menu.
2. Select 5 for the Network Diagnostics.
3. Press 3 to enter the Voice Network Status Menu.
6.2 Network Programming
This Section of the Manual describes how to program the network options using the built-in annunciator. All options described in this
Section can be programmed using the HFSS Programming Tool. To edit the site assignments, you must use HFSS Programming Tool.
6.2.1 Learn Network
The Learn Network Menu shows you all of the panels connected to the network. Any panel that has been programmed into the network
will appear as a “Member.” Any panel that is connected to the network but not programmed into the network will appear as a “Guest.”
You can add Guest panels to the network by changing their status to a Member in this Menu. The Panels showing OK are currently
responding on the network. The Panels not showing OK have either been removed or are not responding due to the networking prob-
lems. See Section 6.1 for Network Diagnostics.
1. Enter the Installer Code. The panel will automatically access the Main Menu.
2. Select 6 for the Network Programming.
3. Press 1 to enter the Learn Network Menu.
4. Press ENTER to add or remove the panels connected to the network as a Member or Guest.
6.2.2 Edit Network Names
The Edit Network Menu allows you to edit the panel name and edit the panels site name.
To Edit Panel Names:
1. Enter the Installer Code. The panel will automatically access the Main Menu.
2. Select 6 for the Network Programming.
3. Press 2 to enter the Edit Network Names Menu.
4. Press 1 to edit the Panel Name. Choose the Panel you want to edit.
To Edit Site Names:
5. Press 2 to edit the Site Name. Choose the Site you want to edit.
See “Editing Text Using the Built-In Programmer” on page 206 for a list of available characters and their numeric designators.
6.2.3 Edit Panel ID
This Menu option allows you to change the current Network Panel ID. It is best to carefully consider the Network ID setting for each
panel. Take into account any future panels that will be added to the network (future wiring of two buildings together). The Network
Panel ID setting must be assigned a unique ID for each panel on the network.
This menu will allow you to change the currently assigned Network Panel ID to the current Network ID dip switch setting. The System
will be down as the panel needs to reboot in order to complete the transition.
When you use the PC Configuration Software to program the panels, the Network Panel ID will be locked from future editing. The only
way to change it will be to restore defaults and use this Menu again.
NOTE: If you add panels to the network, the System will automatically run the Sync Network Options. You will be required to select from
which panel to distribute the network options. See Section 6.4.
