Point Programming
FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 103
4. Press the up or down arrow key to select the desired module. Refer to Section “Programming Menu Quick Reference” on
page 108 for available choices. Then press ENTER.
.
Figure 9.7 Programming Points Screen for the FIK-AMP Module
5. Enter the point number, then press ENTER.
Points 5-8 on the FIK-50W or the FIK-125W will not be available unless the FIK-CE4 is installed.
6. Press the up or down arrow key to select the type (notification or unused), then press ENTER.
7. Press ENTER to edit the point name. See “Editing Text Using the Built-In Programmer” on page 206. Or Press theright
arrow key to skip the Point Name Edit.
8. Repeat Steps 1 through 7 for all points.
9.5.6 Point Programming for FIK-NVCM and FIK-RVM Modules
To program FIK-NVCM and FIK-RVM module points, do the following.
1. Enter the Installer Code.
2. Select 7 for the Program Menu.
3. Press 4 to enter the Point Menu.
4. Press the up or down arrows to select the desired module. Refer to Section “Programming Menu Quick Reference” on
page 108 for available choices. Press ENTER.
Figure 9.8 Programming Points Screen for the FIK-NVCM or FIK-RVM Modules
5. Enter the point number. Press ENTER.
6. Press the up or down arrows to select the type (Switch or unused). Press ENTER.
7. Press the up or down arrows to select the function. Press ENTER.
8. Use the up or down arrows to modify the remaining options and press ENTER to move the cursor to the next field.
9. Edit the module name. See “Editing Text Using the Built-In Programmer” on page 206 or, Press the right arrow to skip
the Module Name Edit.
10. Repeat Steps 1 through 9 for all points.
M04 P004 NOTIF
G001
MODULE_1 CKT_8
<Enter Point or <= to Exit>
Enter Point
Select NOTIF or Unused
Select a name
for the Point
Choices Type Selections
Function Selections for
each Type
Comments
FIK-5880 (output) UNUSED
NOTIF
(outputs pt 1-40)
NOTIF OUTPUT
CONTROL CIRCUIT
Table 9.7 Point Programming Options for FIK-NVCM and FIK-RVM
M04 P004 NOTIF
G001
MODULE_1 CKT_8
<Enter Point or <= to Exit>
Enter Point
Select SWITCH
Select a name
for the Point
or Unused
