138 FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021
Reporting Receivers Compatible with the Control Panel
User initiated manual dialer test RX 0 RXNN000000 1 601 00 000
Walk Test begin TS 0 TSNN000000 1 607 00 000
Walk Test end TE 0 TENN000000 3 607 00 000
Table 12.2 Zone Events
Note: Zone events are reported only when “Report by Zone” is selected
Auxiliary power trouble FT 0000 FTNN000000 1 320 00 000
Auxiliary power trouble restore FJ 0000 FJNN000000 3 320 00 000
CO Detector Alarm GA Zone # GANN000ZZZ 1 162 00 Zone #
CO Detector Alarm Restore GH Zone # GHNN000ZZZ 3 162 00 Zone #
CO Detector Supervisory Alarm GS Zone # GSNN000ZZZ 1 200 00 Zone #
CO Detector Supervisory Alarm Restore GR Zone # GRNN000ZZZ 3 200 00 Zone #
CO Detector Trouble GT Zone # GTNN000ZZZ 1 373 00 Zone #
CO Detector Trouble Restore GJ Zone # GJNN000ZZZ 3 373 00 Zone #
Detector Alarm FA Zone # FANN000ZZZ 1 110 00 Zone #
Detector Alarm Restore FH Zone # FHNN000ZZZ 3 110 00 Zone #
Detector trouble FT Zone # FTNN000ZZZ 1 373 00 Zone #
Detector trouble restore FJ Zone # FJNN000ZZZ 3 373 00 Zone #
ECS Switch Trouble QT 0 QTNN000000 1 242 00 000
ECS Switch Trouble Restore QJ 0 QJNN000000 3 242 00 000
ECS Supervisory/Tamper Alarm QS 0 QSNN000000 1 241 00 000
ECS Supervisory/Tamper Alarm
Restore
QR 0 QRNN000000 3 241 00 000
ECS Output Group Trouble QT Group # +1000 QTNN001GGG 1 320 00 Group #
ECS Output Group TroubleRestore QJ Group # +1000 QJNN001GGG 3 320 00 Group #
External Reset/Silence/Fire Drill switch
trouble
UT 0000 UTNN000000 1 373 00 000
External Reset/Silence/Fire Drill switch
trouble restore
UJ 0000 UJNN000000 3 373 00 000
LOC Mic Activated ECS Alarm QA 0 QANN000000 1 220 00 000
LOC Mic Activated ECS Alarm Restore QH 0 QHNN000000 3 220 00 000
LOC/Point ECS # Alarm QA Emergency # QANN0E0000 1 220 +
Emer-
gency #
00 000
LOC/Point ECS # Alarm Restore QH Emergency # QHNN0E0000 3 220 +
Emer-
gency #
00 000
Manual pull switch alarm FA Zone # FANN000ZZZ 1 115 00 Zone #
Manual pull switch alarm restore FH Zone # FHNN000ZZZ 3 115 00 Zone #
Manual pull switch trouble FT Zone # FTNN000ZZZ 1 373 00 Zone #
Manual pull switch trouble restore FJ Zone # FJNN000ZZZ 3 373 00 Zone #
Notification output trouble FT Group # + 1000 FTNN001GGG 1 320 00 Group #
Notification output trouble restore FJ Group # + 1000 FJNN001GGG 3 320 00 Group #
Positive Alarm Sequence acknowledge
switch trouble
FT Zone # FTNN000ZZZ 1 373 00 Zone #
Positive Alarm Sequence acknowledge
switch trouble restore
FJ Zone # FJNN000ZZZ 3 373 00 Zone #
SLC LED Module trouble ET 0000 ETNN000000 1 333 00 000
SLC LED Module trouble restore ER 0000 ERNN000000 3 333 00 000
Status Point Types Trouble UT 0 UTNN000000 1 379 00 000
Status Point Types Trouble Restore UJ 0 UJNN000000 3 379 00 000
Supervisory Detector Alarm FS Zone # FSNN000ZZZ 1 200 00 Zone #
Supervisory Detector Alarm Restore FR Zone # FRNN000ZZZ 3 200 00 Zone #
SIA Reporting Format Contact ID Reporting Format
SIA pi Modifier SIA
Event Description Module ID
# (If Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN - panel
ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
Table 12.2 Report Formats Table (Continued)
