Fike FCP-300 - Page 140

140 FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021
Reporting Receivers Compatible with the Control Panel
Background Music Switch is Enabled pi Exp. ID UU Point # UUNNXXPPPP 3 580 Exp. ID Point #
CO Detector Trouble pi Exp. ID GT Point # GTNNXXPPPP 1 373 Exp. ID Point #
CO Detector Trouble Restore pi Exp. ID GJ Point # GJNNXXPPPP 3 373 Exp. ID Point #
CO Detector Disabled pi Exp. ID GB Point # GBNNXXPPPP 1 571 Exp. ID Point #
CO Detector Enabled pi Exp. ID GU Point # GUNNXXPPPP 3 571 Exp. ID Point #
Detector Alarm pi Exp. ID FA Point # FANNXXPPPP 1 110 Exp. ID Point #
Detector Alarm restore pi Exp. ID FH Point # FHNNXXPPPP 3 110 Exp. ID Point #
Detector Disabled pi Exp. ID FB Point # FBNNXXPPPP 1 571 Exp. ID Point #
Detector Enabled pi Exp. ID FU Point # FUNNXXPPPP 3 571 Exp. ID Point #
Detector Trouble pi Exp. ID FT Point # FTNNXXPPPP 1 373 Exp. ID Point #
Detector Trouble restore pi Exp. ID FJ Point # FJNNXXPPPP 3 373 Exp. ID Point #
Detector CO Alarm pi Exp. ID GA Point # GANNXXPPPP 1 162 Exp. ID Point #
Detector CO Alarm Restore pi Exp. ID GH Point # GHNNXXPPPP 3 162 Exp. ID Point #
Detector CO Supervisory Alarm pi Exp. ID GS Point # GSNNXXPPPP 1 200 Exp. ID Point #
Detector CO Supervisory Alarm Restore pi Exp. ID GR Point # GRNNXXPPPP 3 200 Exp. ID Point #
ECS Alarm # Point Alarm pi Exp. ID QA (EPPP) E - Emergen-
cy #
PPP - Point #
QANNXXEPPP 1 220 +
Emer-
gency #
Exp. ID Point #
ECS Alarm # Point Alarm Restore pi Exp. ID QH (EPPP) E - Emergen-
cy #
PPP - Point #
QHNNXXEPPP 3 220 +
Emer-
gency #
Exp. ID Point #
ECS Alarm # Point Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 242 Exp. ID Point #
ECS Alarm # Point Trouble Restore pi Exp. ID QJ Point # QJNNXXPPPP 3 242 Exp. ID Point #
ECS Alarm # Point Disabled pi Exp. ID QB Point # QBNNXXPPPP 1 243 Exp. ID Point #
ECS Alarm # Point Enabled pi Exp. ID QU Point # QUNNXXPPPP 3 243 Exp. ID Point #
ECS Supervisory/Tamper Alarm pi Exp. ID QS Point # QSNNXXPPPP 1 241 Exp. ID Point #
ECS Supervisory/Tamper Alarm Restore pi Exp. ID QR Point # QRNNXXPPPP 3 241 Exp. ID Point #
ECS Supervisory/Tamper Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 242 Exp. ID Point #
ECS Supervisory/Tamper Trouble
Restore
pi Exp. ID QJ Point # QJNNXXPPPP 3 242 Exp. ID Point #
ECS Supervisory/Tamper Disabled pi Exp. ID QB Point # QBNNXXPPPP 1 243 Exp. ID Point #
ECS Supervisory/Tamper Enabled pi Exp. ID QU Point # QUNNXXPPPP 3 243 Exp. ID Point #
ECS NAC Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
ECS NAC Trouble Restored pi Exp. ID QJ Point # QJNNXXPPPP 3 320 Exp. ID Point #
ECS Control Circuit Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
ECS Control Circuit Trouble Restored pi Exp. ID QJ Point # QJNNXXPPPP 3 320 Exp. ID Point #
ECS Relay Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
ECS Relay Trouble Restored pi Exp. ID QJ Point # QJNNXXPPPP 3 320 Exp. ID Point #
ECS Notification Trouble pi Exp. ID QT Point # QTNNXXPPPP 1 320 Exp. ID Point #
ECS Notification Trouble Restored pi Exp. ID QJ Point # QJNNXXPPPP 3 320 Exp. ID Point #
External Reset/Silence/Fire Drill switch
disabled
pi Exp. ID UB Point # UBNNXXPPPP 1 571 Exp. ID Point #
External Reset/Silence/Fire Drill switch
enabled
pi Exp. ID UU Point # UUNNXXPPPP 3 571 Exp. ID Point #
External Reset/Silence/Fire Drill switch
trouble
pi Exp. ID UT Point # UTNNXXPPPP 1 373 Exp. ID Point #
External Reset/Silence/Fire Drill switch
trouble restore
pi Exp. ID UJ Point # UJNNXXPPPP 3 373 Exp. ID Point #
Interlock switch alarm (Water Release
Zone)
pi Exp. ID FA Point # FANNXXPPPP 1 110 Exp. ID Point #
SIA Reporting Format Contact ID Reporting Format
SIA pi Modifier SIA
Event Description Module ID
# (If Any)
SIA
Event
Codes
Parameter Fixed Length
Format NN - panel
ID
XX- SBUS ID
ZZZ- Zone #
PPPP- Point #
GGG- Group #
E- Emergency #
RRRR-Receiver #
Qualifier Event
Code
Group # Contact #
Table 12.2 Report Formats Table (Continued)
