Model FCP-300/ECS
Basic Operating Instructions
These instructions must be framed and displayed next to the FCP-300/ECS panel in accordance with the
NFPA 72 Fire Code for Local Protected Fire Alarm Systems.
FS = Fire System ECS = Emergency Communication System
Operation Task to Perform
Silence Alarms and
Troubles
Press SILENCE then enter a code if prompted. Silence LED will light.
Reset Alarms 1. Press RESET.
2. Press 1 to Reset Fire System.
3. Press 2 to Reset Emergency Communication. System.
Note: To reset the ECS at an LOC, the User must gain ECS Control (See Figure 1).
View all active
alarms, troubles, and
supervisory signals
The highest priority event will display first. Press the Down arrow to view location and type of alarm or trouble.
View a Point’s Status 1. Press ENTER to access the Main Menu.
2. Press 2 to select th Point Functions.
3. Then press 2 to select the Point Status.
4. Select the module the device is located on by using the Up or Down button. Then press ENTER.
5. Enter the point number.
Conduct a Fire Drill Hold the DRILL button and then enter a code if prompted. OR
1. Enter the Installer Code. The panel will automatically go to the Main Menu.
2. Press 1 to select System Tests.
3. Enter code if prompted, then press 1 to select Fire Drill.
4. Press ENTER to start the fire drill, and Press ENTER to end the fire drill.
Set Time and Date 1. Press ENTER to access the Main Menu.
2. Then press 4 to select the Set Time & Date. Enter a code if prompted.
3. Make changes in the fields on the screen as necessary.
4. Press ENTER if you want to keep the changes.
5. Press ENTER to set the entered time and date.
Enable / Disable a
Point
1. Rotate the key or enter a code to access to access Main Menu.
2. Press 2 to select Point Functions.
3. Press 1 for Disable / Enable Pt
4. Press 7 for Disable / Enable Pt.
5. Use the Up or Downbutton to move through the list. Then press ENTER to select the module where
the point you want to disable/enable is located
6. Enter the point or circuit number that you want to disable/enable.
7. Press the right arrow key to toggle between NORMAL (enable) or DISABLE.
To Gain / Request
ECS Control
1. Press the Button and follow the on-screen Instructions.
Note: When ECS Control LED is blinking, another LOC has ECS Control. ECS Control LED is on steady when the
LOC has ECS Control.
