Calculating Current Draw and Standby Battery Installation Requirements
FCP-300/FCP-300ECS Manual — P/N LS10145-002FK-E:A 3/12/2021 21
Addressable SLC Devices
FIK-M500M
Standby/Alarm: .375 mA mA mA
FIK-M501M
mA mA
FIK-PULL-SA / FIK-PULL-DA
mA mA
FIK-M500DM
Standby/Alarm: .75 mA mA mA
FIK-IM-10
Standby/Alarm: 3.5 mA mA mA
FIK-M500X
SLC Standby: 375 mA
Alarm: .375 mA
mA
mA
Aux. Power Standby: 1.7 mA mA
Alarm: 7 mA mA
FIK-SC-6
SLC Standby: 2.25 mA
Alarm: 2.25 mA
mA
mA
Aux. Pwr Standby: 8 mA
Alarm: 20 mA
mA
mA
FIK-M500R
Standby/Alarm: .255 mA mA mA
FIK-CR-6
Standby/Alarm: 1.45 mA mA mA
FIK-M500MR-2
Standby: 1.3 mA mA
Alarm: 24 mA mA
FIK-M502M
Aux Pwr Standby: 12 mA mA
Alarm: 90 mA mA
SLC Standby/Alarm: 2 mA mA mA
FIK-CZ-6
Aux Pwr Standby: 70 mA mA
Alarm: per zone 90 mA mA
Alarm: Total with all 6 circuits
active 540 mA
mA
SLC Standby/Alarm: 2 mA mA mA
SLC Accessories
B200SR / IV / WH Sounder Base
Aux Pwr
Standby: .5mA mA
Alarm: 35mA mA
SLC Standby 3mA mA
B200S / IV / WH intelligent Sounder Base
Aux Pwr
Standby: .5mA mA
Alarm: (high vol) 35mA mA
SLC Standby .3mA mA
B200SR-LF / IV / WH Low Frequency
Sounder Base
Aux Pwr
Standby: 1mA mA
Alarm: 125mA mA
B200S-LF/ IV / WH Low Frequency
Sounder Base
Aux Pwr
Standby .55mA mA
Alarm (high vol) 140mA mA
SLC Standby .30mA mA
B224RB / IV /WH Relay Base Standby/Alarm: .5mA mA mA
RTS151/151 KEY
Alarm: 7.5 mA
mA
RA100Z
Alarm: 10 mA
mA
SLC Isolator Devices
FIK-M500X (Isolator Module)
(100 max.) Standby/Alarm: .45 mA mA mA
B224BI/IV Isolator Base
Standby/Alarm: .5 mA
Accessories Modules
FIK-6815 SLC Loop Expander
(63 max.) Standby/Alarm: 78 mA mA mA
Color Guide: -WH = White, -IV = Ivory
FIK-RA2000 Remote LCD Annunciator
(16 max.) Standby: 25 mA mA
Alarm: 50 mA mA
FIK-RA1000 Remote LCD Annunciator
Standby: 20 mA mA
Alarm: 25 mA mA
FIK-RA100 Remote LCD Annunciator
Standby: 20 mA mA
Alarm: 25 mA mA
FIK-5824 Serial / Parallel Module
(4 max.) Standby/Alarm: 45 mA mA mA
FIK-RPS1000 Power Supply
(16 max.) Standby/Alarm: 10 mA mA mA
FIK-5496 NAC Expander
Standby/Alarm: 10 mA mA mA
Device
Number of
Devices
Current per Device
Standby
Current
Alarm Current
Table 3.3 Current Draw Worksheet for Fike SLC Devices (Continued)
