Specifications
Environmental
10
10-11
Environmental
Environmental....................... MIL-PRF-28800F, Class 2
Temperature
Operating ................................ 0 to 50 °C (32 to 122 °F)
Storage .................................-20 to 60 °C (-4 to 140 °F)
Humidity
Operating:
@0 to 10 °C (32 to 50 °F)..................noncondensing
@10 to 30 °C (50 to 86 °F)................................. 95%
@30 to 40 °C (86 to 104 °F).................................75%
@40 to 50 °C (104 to 122 °F)...............................45%
Storage:
@-20 to 60 °C (-4 to 140 °F) ...............noncondensing
Altitude
Operating .......................................... 5 km (16 400 feet)
Max. Input and Floating Voltage 600 Vrms upto 2 km,
> 2 km 300 Vrms <5 km.
Storage ...........................................12 km (40 000 feet)
Vibration (sinusoidal) ....................................................
........... MIL28800F, class 2, 3.8.4.2, 4.5.5.3.1: Max. 3g
Shock...............................................................................
......... MIL28800F, class 2, 3.8.5.1, 4.5.5.4.1: Max. 30g
Electromagnetic Compatibility (EMC)
Emission and Immunity ...............EN/IEC61326-1: 2006
Enclosure Protection ................ IP51, ref: EN/IEC60529
Safety
Designed for measurements on 600 Vrms Measurement
Category III, Pollution Degree 2, per:
• ANSI/ISA S82-02.01
• EN/IEC 61010-1: 2001
• CAN/CSA-C22.2 No.61010-1-04 and UL no. 61010-1-
04 (including
C
CSA
US
approval)
Max. Input Voltage Input A and B
Direct on input or with leads .......................... 600 Vrms
for derating, see Figure 10-1.
With Banana-to BNC Adapter BB120............. 300 Vrms
for derating, see Figure 10-1.
Max. Floating Voltage
from any terminal to ground............................ 600 Vrms
up to 400 Hz
