Saving and Recalling Data Sets
Recalling, Renaming, Deleting Data Sets
6
6-3
Recalling, Renaming, Deleting Data Sets
To recall a data set, do the following:
c
Open the SAVE/RECALL mode.
If no data sets are stored
RECALL DELETE… is disabled
(grey text).
d
Open the RECALL/DELETE
menu.
e
Highlight the data set you want to
recall, rename, or delete.
f
Press F1 to delete the data set
Press F2 to rename the data set;
do steps 3…5 of the ‘Saving Data
Sets procedure.
Press F4 to recall the data set.
Observe that the recalled
waveform is displayed and that
HOLD appears on the screen.
From this point you can use
cursors for analysis or you can
print the recalled screen. The test
tool returns to signal acquisition if
you press the HOLD/RUN key,
using the setting of the recalled
data set.
g
Go back to the save/print mode.
