Fluke 125 User Manual

Scope/Meter Mode
Making Relative Measurements
2
2-9
Making Relative Measurements
Zero Reference displays the present measurement result
with respect to the defined value. This feature is useful
when you need to monitor the measured value in relation
to a known good value.
c Open the A MEASUREMENTS
menu.
d Activate the relative
measurement. (ZERO).
Note
In the OHM Ω measurement function the F1
ZERO ON OFF soft key enables you to turn
relative measurements on and off.
Figure 2-9. Making a Relative Measurement
The relative measurement now becomes the main
reading, while the former main measurement has moved
to the smaller secondary reading position. (See Figure
2-9.)
Do step1 and step 2 again to de-activate the relative
measurement.

Fluke 125 Specifications

General

Channels	2
Safety Rating	CAT III 600 V
Resistance Measurement	Yes
Continuity	Yes
Diode Test	Yes
Harmonics Measurement	Yes
Power Measurement	Yes
Weight	1.2 kg
Current Measurement	Yes
Type	ScopeMeter
Voltage Range	600 V
