Fluke 5320A User Manual

5320A
Users Manual
6-14
Table 6-5. High Resistance Source Limits
Nominal value
Required standard
ohmmeter uncertainty
Lower limit Upper limit
10 kΩ
0.02 %
9.98 kΩ
10.02 k
20 kΩ
0.02 %
19.96 kΩ
20.04 k
40 kΩ
0.02 %
39.92 kΩ
40.08 k
80 kΩ
0.02 %
79.84 kΩ
80.16 k
100 kΩ
0.02 %
99.80 kΩ
100.20 k
200 kΩ
0.02 %
199.6 kΩ
200.4 k
400 kΩ
0.02 %
399.2 kΩ
400.8 k
800 kΩ
0.02 %
798.4 kΩ
801.6 k
1.00 MΩ
0.05 %
997.0 kΩ
1003.0 k
2.00 MΩ
0.05 %
1.994 MΩ
2.006 M
4.00 MΩ
0.05 %
3.988 MΩ
4.012 M
8.00 MΩ
0.05 %
7.976 MΩ
8.024 M
10.0 MΩ
0.1 %
9.95 MΩ
10.05 M
20.0 MΩ
0.1 %
19.9 MΩ
20.1 M
40.0 MΩ
0.1 %
39.8 MΩ
40.2 M
80.0 MΩ
0.1 %
79.6 MΩ
80.4 M
100 MΩ
0.1 %
99.5 MΩ
100.5 M
200 MΩ
0. 1 %
199 MΩ
201 M
400 MΩ
0. 1 %
398 MΩ
402 M
800 MΩ
0. 1 %
796 MΩ
804 M
1.0 GΩ
0.2 %
990 MΩ
1.030 M
2.0 GΩ
0. 2 %
1.98 GΩ
2.06 G
4.0 GΩ
0. 2 %
3.96 GΩ
4.12 G
8.0 GΩ
0. 2 %
7.92 GΩ
82.4 G
100 GΩ
1.0 %
Rcal − 3 GΩ
[1]
Rcal + 3 GΩ
[1]
1.0 GΩ
[2]
0.2 %
0.987 GΩ 1.013 GΩ
10 GΩ
[2]
0.2 %
98.5 GΩ 10.15 GΩ
100 GΩ
[2]
0.5 %
97.5 GΩ 102.5 GΩ
1.0 TΩ
[2]
1 %
0.97 TΩ 1.03 TΩ
10 TΩ
[2]
1 %
9.6 TΩ 10.4 TΩ
[1] Maximum deviation from calibration value.
[2] With resistance multiplier adapter.
