Electrical Specifications 1
1-15
AC/DC Voltage Calibrator (5320A/VLC only)
Range.................................................................3 to 600 V, ac or dc
Resolution ......................................................... 4 digits
Internal Ranges:
AC Mode......................................................... 30, 100, 300, and 600 V (Autoranging only)
DC Mode......................................................... 30, 150, and 600 V (Autoranging only)
Frequency:
Range ............................................................. 40 to 400 Hz
Resolution....................................................... 3 digits
Uncertainty……………………………………… 0.02 %
Settling Time ..................................................... 300 ms to 3 s, depending on output value
AC Voltage
Uncertainty and Maximum Burden Current
Range Resolution
Uncertainty
±(% of Reading + mV)
Maximum Burden Current
3 – 29.99 V 0.001 V 0.1 % + 9 500 mA
30 – 99.99 V 0.01 V 0.1 % + 30 300 mA
100 – 299.9 V 0.1 V 0.1 % + 90 150 mA
300 – 600 V 0.1 V 0.1 % + 180 50 mA
DC Voltage
Uncertainty and Maximum Burden Current
Range Resolution
Uncertainty
±(% of Reading + mV)
Maximum Burden Current
3 – 29.99 V 0.001 V 0.1 % + 9 2 mA
30 – 149.9 V 0.01 V 0.1 % + 45 3 mA
150 – 600 V 0.1 V 0.1 % + 180 5 mA
AC Output Signal Distortion............................ 0.2 % ±10 mV (harmonic distortion and non-harmonic noise from 20
Hz to 500 kHz), for output power lower than 10 VA on each range.
Sensing Ammeter Current Range ................... 500 mA
Resolution ......................................................... 1 mA
Uncertainty ........................................................±5 mA
Multimeter
Voltage
Range.................................................................0 to 1100 V ac rms or dc
Resolution ......................................................... 4½ digits
Internal Ranges.................................................10, 100, and 1100 V (Autoranging only)
Frequency Range..............................................DC, 20 Hz to 2 kHz
Input Resistance............................................... 10 MΩ ±1 %
Time Constant...................................................1.5 s
Readings/Second..............................................2
Measurement Category.................................... 1000 V CAT I, 300 V CAT II
AC/DC Voltage Uncertainty
Range Resolution
Uncertainty
±(% of Reading + mV)
10 V 0.001 V 0.15 % + 5
100 V 0.01 V 0.20 % + 50
1100 V 0.1 V 0.20 % + 550
