Introduction and Specifications

General Specifications 1

1-9

Optional Accessories

Table 1-2 lists optional accessories for the Calibrator.

Table 1-2. Optional Accessories

Model Description

5320CASE Transit case for 5320A Calibrator

Y5320 Rack mount kit for mounting a 5320A in a standard 19 inch rack.

5320A-LOAD Load resistor adapter for hipot leakage current calibration

General Specifications

Warm-Up Time .................................................. 30 minutes

Specifications Confidence Level..................... 99 %

Specifications Interval…………………………...1 year

Temperature Performance

Operating Temperature ..................................18 to 28 °C

Calibration Temperature (tcal)........................ 23 °C

Temperature Coefficient ................................. Temperature coefficient for temperature outside of Tcal ±5 °C between

+5 °C to +40 °C is 0.1 x /°C

Storage Temperature...................................... -20 to +70 °C

Relative Humidity (operating).......................... <70 % to 28 °C

Altitude

Operating........................................................ 3,050 m (10,000 ft.)

Storage ........................................................... 12,200 m (40,000 ft.)

Dimensions ....................................................... 450 mm X 480 mm X 170 mm (17.7 in. X 18.9 in. X 6.7 in.)

Weight................................................................18 kg (39.7 lb)

Power Line......................................................... 115/230 V ac (50/60 Hz) ±10 %

Power Consumption.........................................150 VA Maximum

Safety Class ......................................................Class I, Bonded Enclosure

Electrostatic Discharge....................................This instrument meets class I for ESD requirements per EN 61326

(Criteria A)

W Fuse Protection

AC mains input ...............................................2 A, 250 V for 230 V, Time delay (T2L250 V – 5 x 20 mm)

4 A, 250 V for 115 V, Time delay (T4L250 V – 5 x 20 mm)

RCD input ....................................................... 3.15 A, 250 V, Fast (F3.15L250V – 5 x 20 mm)

Meter amps (A) input ...................................... 20 A, 500 V, Time delay (T20L500V – 6.3 x 32 mm)

Loop/Line impedance input............................. 4 A, 250 V, Time delay (T4L250V – 6.3 x 32 mm)

Leakage current input..................................... 100 mA, 150V, Fast (F100mL150V – 5 x 20 mm)
