Tips for troubleshooting
141
16.3 Clearing a letter jam in the feeder
Warning: Mind Your Hands! The mechanism is pressed by springs to the
letter guide. It does not lock when released, but snatches back. Be cautious
when removing jammed letters from the letter path.
• Turn release knob toward the position
till stop and hold in that position
(1).
The pressure mechanism is released and
unclamps the letter.
• Carefully remove the stuck letter to the
top right (2).
• Let the release knob snatch back guard-
edly to initial position .
The pressure mechanism is set back to
processing position. The feeder is ready
to operate.
• Please heed the information on the frank-
ing machine’s display.
If you cannot clear a letter jam by following
the above instructions:
• Pull cover from feeder (refer to page 18).
• Remove letter as described above.
• Re-place cover on feeder (refer to page 19).
