Appendix – Moving the PostBase One to another location
169
On the franking machine • Connect the network cable to the network
connection on the side of the franking
machine. Please check the correct position
of the spring.
• Plug the connection cable of the static
scale into the scale connection of the frank-
ing machine.
• Plug the power cable into the power socket
of the franking machine.
Depending on the system’s configuration:
• Insert either the connection cable of the
dynamic scale / the sealer / the feeder or
the termination plug into the 15-pin inter-
face and tighten screws.
Scale con-
nection
Network connection Spring
Power connection
Interface
(15-pin)
Connection
cable
