202
PostBase One (franking machine)
Display / touch screen (hinged)
Hand feed tray
Label dispenser
Letter guide face (black)
Protective glass
Fleece tray
with ink fleece
9-pin interface
(power sealer connection)
Letter catch
tray
Safety sign
To adjust the display incli-
nation: Press the key
Stylus for touch screen operation
(stored either left or right in a receptacle on the back of the display housing)
Static scale
Weighing
platform
Power connection
Rocker switch (ON / OFF)
Battery compartment
Flap, with print system
below
CAN BUS
Ventilation slots
Interfaces:
USB port
PC connection
Serial interface
Ethernet / LAN port (LAN)
Static scale connection
Interface for connection of
optional components
(e.g. feeder, sealer)
