4.5 Switching the Applicable Motor Rating (HHD/HND Specifications)
4-6
4.5 Switching the Applicable Motor Rating (HHD/HND Specifications)
By switching from the factory default HHD specification to the HND specification on three-phase 200V series and
three-phase 400V series inverters, they can be used with a motor reference rated current of one to two ranks
higher. However, the overload capability will drop.
Double key operation ( key + / keys) is required to change function code F80 data.
Table 4.5-1
F80
data
Specification
type
Application
Continuous current rating level
Overload
capability
0
HHD
specification
Heavy load
Capable of driving a motor whose
capacity is the same as the inverter
capacity.
150% for
1 min, 200%
for 3 s
1
HND
specification
Standard load
Capable of driving a motor with
capacity one to two ranks higher than
the inverter capacity.
120% for
1 min
 Some models are incompatible with the HND specification depending on the inverter rated voltage and
capacity. Please refer to Chapter 12 “SPECIFICATIONS”.
HHD/HND specification inverters are subject to restrictions on the function code data setting range and internal
processing as listed below.
Table 4.5-2
Function
code
Name
HHD specification
HND specification
Remarks
F21 *
DC braking 1
(Braking level)
Setting range: 0 to 100%
Setting range: 0 to 80 %
With the HND
specification, a value out
of the range, if specified,
automatically changes to
the maximum value
allowable for the HND
specification.
F26
Motor sound
(Carrier frequency)
Setting range
0.75 to 16 kHz
(FRN0003G2S-2G to
FRN0288G2S-2G）
(FRN0002G2■-4G to
FRN0150G2■-4G）
0.75 to 10 kHz
(FRN0346G2S-2G to
FRN0432G2S-2G）
(FRN0180G2■-4G to
FRN1386G2■-4G）
Setting range
0.75 to 16 kHz
(FRN0032G2S-2G to
FRN0088G2S-2G）
(FRN0018G2■-4G to
FRN0045G2■-4G）
0.75 to 10 kHz
(FRN0115G2S-2G to
FRN0288G2S-2G）
(FRN0060G2■-4G to
FRN0150G2■-4G）
0.75 to 6 kHz
(FRN0346G2S-2G to
FRN0432G2S-2G）
(FRN0180G2■-4G to
FRN1386G2■-4G）
F44
Current limiter
(Level)
Initial value: 180%
(FRN0075G2S-2G/FRN0038
G2■-4G or below)
Initial value: 160%
(FRN0088G2S-2G/FRN0045
G2■-4G or above）
Initial value: 130%
When changing F80, the
value is rewritten with the
value on the left.
-
Current indication
and output
Based on the rated current
level for HHD specification
Based on the rated
current level for HND
specification
Switching between the drive modes does not automatically change the motor rated capacity (P02*) to the one
suitable for the rank-changed motor, so configure the P02* data to match the applied motor rating as required.
