Fuji Electric FRENIC MEGA G2 Series - Page 216

5.2 Function Code Tables
5-32
Function
code
Name
Control method and Data setting range
Change when running
Data copying
Factory
default
Related page
r43
Speed control 4
(Speed command filter)
Same as A43
Y
Y
0.020
5-296
r44
(Speed detection filter)
Same as A44
Y*
Y
0.005
r45
(P gain)
Same as A45
Y*
Y
10.0
r46
(I integral time)
Same as A46
Y*
Y
0.100
r47
FF (Gain)
Same as A47
Y*
Y
0.00
r48
(Output filter)
Same as A48
Y
Y
0.002
r49
(Notch filter resonance
frequency)
Same as A49
Y
Y
200
5-299
r50
(Notch filter attenuation
level)
Same as A50
Y
Y
0
r51
Cumulative run time of motor
4
Same as A51
N
N
0
-
r52
Startup count for motor 4
Same as A52
Y
N
0
r53
Motor 4
(%X correction factor 1)
Same as A53
Y
Y1Y2
100
r54
(%X correction factor 2)
Same as A54
Y
Y1Y2
100
r55
(Torque current under vector
control)
Same as A55
N
Y1Y2
*6
r56
(Induced voltage factor
under vector control)
Same as A56
N
Y1Y2
*6
r57
(For adjustment by
manufacturer *9)
Same as A57
Y
Y1Y2
*6
r58
Speed control 4
(Notch filter width)
Same as A58
Y
Y
2
r60
Speed display coefficient 4
Same as A60
Y
Y
0.00
r61
Constant rate of feeding
coefficient 4/
Speed display auxiliary
coefficient 4
Same as A61
Y
Y
1.000
r62
Starting frequency 4
(Holding time)
Same as A62
Y
Y
0.00
r63
Stop frequency 4
Same as A63
Y
Y
999
r64
(Detection method)
Same as A64
N
Y
100
r65
(Holding time)
Same as A65
Y
Y
0.00
r66
Motor 4
(Thermistor operation
selection)
Same as A66
Y
Y
100
r67
(Operation level)
Same as A67
Y
Y
0.35
r98
(Function selection)
Same as A98
N
Y
0
*9: This is a function code for adjustment by the manufacturer. Do not access these function codes.
*10: 5.0 min for FRN0115G2S-2G/FRN0060G2-4G or lower inverters, 10.0 min for FRN0146G2S-2G/FRN0075G2-4G or higher inverters
