5.2 Function Code Tables


Control method and Data setting range
Brake control signal
  (Brake-release current)
(Brake-release
frequency/speed)
(Brake-applied
frequency/speed)
*1:  When speed control (dancer) is selected (J01 ≠ 3 → = 3), the J06 setting value automatically changes to 0.0 s. To specify the filter time constant
in detail, apply filter time constants for analog input (C33, C38 and C43) with J06 = 0.0. When speed control (dancer) is not selected (J01 = 3
→ ≠ 3), the J06 setting value automatically changes to 0.5 s. Set J06 after setting J01.


Control method and Data setting range
Overload stop
(Stopper contact)
  (Torque limiting P (Gain))
(Torque limiting I
(Integral time))
Brake control signal
  (Brake-release torque)
0 to 127
Bit 0:  Speed detection / Speed command selection
(0: Speed detection value, 1: Speed command value)
Bit 1:  Reserved
Bit 2:  Not used
Bit 3:  Not used
Bit 4:  Brake-apply condition
(0: Regardless of run command status (ON or OFF),
1: Only when run command is OFF)
Bit 5:  Not used
Bit 6:  Stop condition at position control
(0Break signal OFF1Break signal ON)
PID control  (Display unit)

0 to 92
0:  Inherit (PID Control 1 feedback unit)
1:  No unit
2:  %
4:  r/min
7:  kW
8:  HP
10:  mm/s
11:  mm/m
12:  mm/h
13:  m/s
14:  m/min
15:  m/h
16:  FPS
17:  FPM
18:  FPH
[Flow]
20:  m
3
/s
21:  m
3
/min
22:  m
3
/h
23:  L/s
24:  L/min
25:  L/h
26:  GPS
27:  GPM
28:  GPH
29:  CFS
30:  CFM
31:  CFH
32:  kg/s
33:  kg/m
34:  kg/h
35:  lb/s
36:  lb/m
37:  lb/h
