PID display coefficient and monitoring
To monitor the PID command and its feedback value, set the scale to convert the values into easy-to-understand
physical quantities such as temperature. The display unit cannot be used on the standard keypad. Use with the
multi-function keypad (TP-A2SW).
Display unit
Maximum scale
Minimum scale
Terminal [12]
C58
C59
C60
Terminal [C1] (C1)
C64
C65
C66
Terminal [V2]
C70
C71
C72
Terminal [C1] (V3)
C84
C85
C86
 Refer to function codes C59, C60, C65, C66, C71, C72, C85, and C86 for details on scales, and to E43 for
details on monitoring.
 Display unit (J105)
J105 can select the display units for monitoring PID feedback value with the multi-function keypad (TP-A2SW).
Setting “0” selects the factory default unit for the PID feedback value.
J105
Display unit
J105
Display unit
J105
Display unit
0
* (Factory default)
26
GPS
48
inWG (pressure)
1
No unit
27
GPM
49
inHg
2
%
28
GPH
50
WC
4
r/min
29
CFS
51
FT WG
7
kW
30
CFM
60
K (temperature)
8
HP
31
CFH
61
°C (temperature)
10
mm/s
32
kg/s
62
°F (temperature)
11
mm/m
33
kg/m
65
N·m
12
mm/h
34
kg/h
66
lb ft
13
m/s
35
lb/s
70
mm
14
m/min
36
lb/m
71
cm
15
m/h
37
lb/h
72
m
16
FPS
38
AF/Y
73
km
17
FPM
40
Pa (pressure)
74
in
18
FPH
41
kPa (pressure)
75
Ft
20
m3/s (flow)
42
MPa (pressure)
76
Yd
21
m3/min (flow)
43
mbar (pressure)
77
mi
22
m3/h (flow)
44
bar (pressure)
80
ppm (concentration)
23
L/s (flow)
45
mmHg (pressure)
90
m
3
24
L/min (flow)
46
Psi (pressure)
91
L
25
L/h (flow)
47
mWG (pressure)
92
GAL
* The unit and scale for feedback values are used.
