Fuji Electric FRENIC MEGA G2 Series - Page 780

11.10 Compact Power Regeneration PWM Converter
11-52
11.10.2 Device Configuration
[ 1 ] Device configuration table
Voltage
Applicable
motor
[kW]
Type
Boosting reactor
Filter resistor
Filter reactor
Filter capacitor
(Lr)
Qty
(Rf)
Qty
(Lf)
Qty
(Cf)
Qty
200V series
5.5
RHC5.5C-2EJ
LR2C-7.5E
1
RF80-0.42OHM
3
LFC2C-7.5E
1
CF2C-7.5E
1
7.5
RHC7.5C-2EJ
11
RHC11C-2EJ
LR2C-15E
1
RF150-0.2OHM
3
LFC2C-15E
1
CF2C-15E
1
15
RHC15C-2EJ
18.5
RHC18.5C-2EJ
LR2C-22E
1
RF200-0.13OHM
3
LFC2C-22E
1
CF2C-22E
1
22
RHC22C-2EJ
400V series
5.5
RHC5.5C-4EJ
LR4C-7.5E
1
RF80-1.74OHM
3
LFC4C-7.5E
1
CF4C-7.5E
1
7.5
RHC7.5C-4EJ
11
RHC11C-4EJ
LR4C-15E
1
RF150-0.79OHM
3
LFC4C-15E
1
CF4C-15E
1
15
RHC15C-4EJ
18.5
RHC18.5C-4EJ
LR4C-22E
1
RF200-0.53OHM
3
LFC4C-22E
1
CF4C-22E
1
22
RHC22C-4EJ
30
RHC30C-4EJ
LR4C-37E
1
RF400-0.38OHM
3
LFC4C-37E
1
CF4C-37E
1
37
RHC37C-4EJ
45
RHC45C-4EJ
LR4C-55E
1
RF400-0.26OHM
3
LFC4C-55E
1
CF4C-55E
1
55
RHC55C-4EJ
75
RHC75C-4EJ
LR4C-75E
1
RF400-0.38OHM
3
LFC4C-75E
1
CF4C-75E
1
Voltage
Applicable
motor
[kW]
Type
Charging circuit contactor
Charging circuit
(73)
Qty
Charging resistor
(R0)
Qty
Fuse (F)
Qty
200V series
5.5
RHC5.5C-2EJ
SC-5-1
1
CR80-7.5OHM
3
CR2LS-50S/UL
2
7.5
RHC7.5C-2EJ
11
RHC11C-2EJ
SC-N1
1
CR2LS-75S/UL
2
15
RHC15C-2EJ
SC-N2
1
CR2LS-100S/UL
2
18.5
RHC18.5C-2EJ
SC-N3
1
CR120-2OHM
3
22
RHC22C-2EJ
CR2L-150S/UL
2
400V series
5.5
RHC5.5C-4EJ
SC-05
1
CR60-30OHM
3
CR6L-30S/UL
2
7.5
RHC7.5C-4EJ
11
RHC11C-4EJ
SC-4-0
1
CR6L-50S/UL
2
15
RHC15C-4EJ
SC-5-1
1
18.5
RHC18.5C-4EJ
SC-N1
1
CR80-7.5OHM
3
22
RHC22C-4EJ
CR6L-75S/UL
2
30
RHC30C-4EJ
SC-N2
1
CR6L-100S/UL
2
37
RHC37C-4EJ
SC-N2S
1
CR6L-150S/UL
2
45
RHC45C-4EJ
SC-N3
1
55
RHC55C-4EJ
SC-N4
1
CR6L-200S/UL
2
75
RHC75C-4EJ
SC-N5
1
Note 1) Filter resistors (Rf) and charging resistors (RO) come in sets of three.
When placing your order, three items will be shipped if "1" is specified for the quantity.
Note 2) Charging circuit contactors and fuses are products of Fuji Electric FA Components & Systems Co., Ltd.
