11.22 Built-in Option Card Types and Ports in Which They Can be Installed
11-119
SELECTING PERIPHERAL EQUIPMENT
Chap 11
Table 11.22-35 Analog input terminal [32] function code setting content
Function
code
Function code content
LED
Data content
Factory default
o75
Terminal [C2]
(Range selection)
0
4 to 20 mA (0 to 100%)
0
1
0 to 20 mA (0 to 100%)
10
4 to 20 mA (-100 to
100%)
11
0 to 20 mA (-100 to
100%)
o76
(Function selection)
0
Refer to E61 to E63
(extension function
selection) in Chapter 5
"FUNCTION CODES".
0: No extension
function
assignment
to
20
o77
(Offset adjustment)
-5.0 to +5.0%
Offset adjustment value
0.0
o78
(Gain adjustment)
0.00 to 200.00%
Gain adjustment value
100.00
o79
(Filter setting)
0.00 to 5.00 s
Filter constant
0.05
o81
(Gain reference point)
0.00 to 100.00%
Gain reference point
100.00
o82
(Bias)
-100.00 to 100.00%
Bias adjustment value
0.00
o83
(Bias reference point)
-100.00 to 100.00%
0.00
o85
(Display unit)
1 to 80
Refer to J105 to J107
(PID control) in Chapter
5 "FUNCTION CODES".
2
o86
(Maximum scale)
-999 to 0.00 to 9990
100.0
o87
(Minimum scale)
-999 to 0.00 to 9990
0.00
