Fuji Electric FRENIC MEGA G2 Series - Page 846

11.22 Built-in Option Card Types and Ports in Which They Can be Installed
11-118
Function code settings
Table 11.22-35 Analog input terminal [32] function code setting content
Function
code
Function code content
LED
Data content
Factory default
o60
Terminal [32]
(Function selection)
0
Refer to E61 to E63
(extension function
selection) in Chapter 5
"FUNCTION CODES".
0: No extension
function
assignment
to
20
o61
(Offset adjustment)
-5.0 to +5.0%
Offset adjustment value
0.0
o62
(Gain adjustment)
0.00 to 200.00%
Gain adjustment value
100.00
o63
(Filter setting)
0.00 to 5.00 s
Filter constant
0.05
o64
(Gain reference point)
0.00 to 100.00%
Gain reference point
100.00
o65
(Polarity selection)
0
Bipolar
1
1
Unipolar
o66
(Bias)
-100.00 to 100.00%
Bias adjustment value
0.00
o67
(Bias reference point)
0.00 to 100.00%
Bias reference point
0.00
o69
(Display unit)
1 to 80
Refer to J105 to J107
(PID control) in Chapter
5 "FUNCTION CODES".
2
o70
(Maximum scale)
-999 to 0.00 to 9990
100
o71
(Minimum scale)
-999 to 0.00 to 9990
0.00
