11.22 Built-in Option Card Types and Ports in Which They Can be Installed
11-117
SELECTING PERIPHERAL EQUIPMENT
Chap 11
Connection example
Table 11.22-34
Terminal
symbol
Connection method
[32]
󳛦󳜫󳜚󳛸󱤛
【P10】
【32】
【31】
󰈻󰡍󰡁󰂟
1 k～5 kΩ
[C2]
󳛦󳜫󳜚󳛸󱤛
【C2】
󰎤󲝢󰼗󰿜
4～20 mA
【31】
[Ao]
󳛦󳜫󳜚󳛸󱤛
【Ao+】
【Ao-】
V
[CS]
󳛦󳜫󳜚󳛸󱤛
【CS+】
【CS-】
A
Variable resistor
1 to 5 kΩ
Shielded line
Constant current source
4 to 20 mA
Shielded line
Shielded line
Shielded line
