Appendix G Conformity with Standards
Appendix-29
APPENDICES
Appendix G Conformity with Standards
G.1 Compliance with European Standards
( )
The CE marking on Fuji products indicates that they comply with the essential requirements of the Electromagnetic
Compatibility (EMC) Directive, Low Voltage Directive, and Machinery Directive issued by the Council of the
European Communities.
Keep the ambient temperature to 50°C or less to comply with European standards.
Products with no standards indicated do not comply with European Standards.
Table G.1-1 Compliance standards
Standards
EMC Directive
EN 61800-3
Immunity: Second environment (Industrial)
Emission: Category C2 or C3
(Refer to Table G.1-2. Applicable only when an optional EMC-compliant filter is
attached.)
: Category C3 (Applicable only to the EMC filter built-in type of inverters)
Low Voltage
Directive
Adjustable speed electrical power drive systems.
Part 5-1: Safety requirements. Electrical, thermal and energy EN61800-5-1:2007
Machine
Directives
EN ISO 13849-1
EN 60204-1
EN 61800-5-2
EN 62061
: Cat.3 PL:e
: Stop Category 0
: SIL3 (Functional Safety : STO)
: SIL3
* A basic type inverter that does not have a built-in EMC filter complies with the EMC Directive by combining it with
an external filter dedicated to Fuji.
Warning
Category C2 : In a domestic environment this product may cause radio interference in which case supplementary
mitigation measures may be required.
Category C3: This type of PDS is not intended to be used on a low-voltage public network which supplies domestic
premises ; radio frequency interference is expected if used on such a network.
Category C2 and C3 : It has a risk about other equipment malfunction or breakdown by radiated electric field
strength out of frequency range that is defined EN 61800-3: 2004 + A1: 2012 2nd
Environment and EN/IEC 61800-3: 2018 2nd Environment.
[ 1 ] Compliance with EMC standards
The CE marking on inverters does not ensure that the entire equipment including our CE-marked products is
compliant with the EMC Directive. Therefore, CE marking for the equipment shall be the responsibility of the
equipment manufacturer. For this reason, Fuji’s CE mark is indicated under the condition that the product shall be
used within equipment meeting all requirements for the relevant Directives. Instrumentation of such equipment shall
be the responsibility of the equipment manufacturer.
Generally, machinery or equipment includes not only our products but other devices as well. Manufacturers,
therefore, shall design the whole system to be compliant with the relevant Directives.
◼ List of EMC-compliant filters
To comply with standards, either use an inverter with built-in EMC filter, or use an inverter with no built-in EMC filter
in combination with a dedicated Fuji external filter (option). No matter what the application, please install noise filters
using the following recommended installation method. It is recommended that noise filters be installed inside metal
cabinets to ensure more reliable compliance with standards.
Our EMC compliance test is performed under the following conditions.
Wiring length (of the shielded cable) between the inverter (EMC filter built-in type) and motor: 5 m
To use Fuji inverters in combination with a PWM converter, the basic type of inverters having no built-in
EMC filter should be used. Use of an EMC filter built-in type may increase heat of capacitors in the inverter,
resulting in damage. In addition, the effect of the EMC filter can no longer be expected.
