Fuji Electric Time Delta-C FSV-2 User Manual

-28-
(2) Setting method when sensor type is not “FSSA”
Operation
(example)
Carry out setting for measuring the flow rate of water flowing through PVC pipe (for tap water) having 100 mm of
nominal diameter, using FSSC detector.
* Settings of piping and fluid to be measured are omitted, since it is same as “(1) Setting method when sensor type
is “FSSA”
Key operation Description Display
▼
Press the key for 3 times to display “MEASURE SETUP”.
MEASURE SETUP
ENT
▼
Press the
ENT
key once to display “SYSTEM UNIT”.
SYSTEM UNIT
METRIC
▼
Press the key for 3 times to display “PROCESS SETTING”.
PROCESS SETTING
S= 31 ( 93mm)
ENT
▼
Press the
ENT
key once to display “OUTER DIAMETER”.
OUTER DIAMETER
114.00 mm
▼
Press the key for 7 times to blink the cursor.
SENSOR TYPE
FSSA/FSSG
ENT
▼
Press the
ENT
key once to blink the cursor.
SENSOR TYPE
FSSA/FSSG
▼
Press the key for 2 times to display “FSSC” on the 2nd line.
SENSOR TYPE
FSSC
ENT
▼
▼
▼
▼
Press the
ENT
key once to register “FSSC”.
SENSOR TYPE

COMPLETE

↓
――― “FSSC” has been registered. ―――
SENSOR TYPE
FSSC
ESC
▼
Press the
ESC
key once to display “PROCESS SETTING”.
“S=58.43mm” is displayed on the 2nd line.
Align the sensor mounting spacing to 58.43mm, and attach the sensor to
the pipe.
PROCESS SETTING
S= 58.43mm
ESC
Press the
ESC
key once and the key twice to return to the
measurement mode.
0.000 m/s
0.000 m3/h
