Chapter 8 Operational Settings
136
Index
Appendix
Introduction
Glossary
Contents
TOP
Loading
Documents
Scan
Parameters
Various
Documents
Daily Care
Trouble-
shooting
Operational
Settings
Consumables
Scanner
Overview
Yes: Configurable
*1: Depending on the "PART NO." on the product label, the factory default setting differs as follows:
For details about product labels, refer to "7.5 Checking Labels on the Scanner" (on page 132).
Item Explanation Selectable Parameters Default Connection via
SCSI/USB
Connector
For connection
via VRS option:
Page Counter
(Consumables
counters)
For evaluating the consumable
replacement cycle.
Use this function to reset the
counters after replacing the consum-
ables.
After cleaning/Brake Roller/Pick Roller 0 pages Yes Yes
Remaining Ink (only when the imprinter
option for fi-6670 is installed)
Shown only
when the
imprinter
option for fi-
6670 is
installed.
Power saving Specify the waiting time before
entering the Power saving mode.
Setting range: 15 to 55 min. (in steps of
5 min.)
15 min. Yes Yes
Power off after a certain period of time:
Select to have the scanner turn off
automatically when it is turned on and
left unused for a certain period of time.
Also, specify the time until power-off.
[Power off after a certain period of time]
check box
(*1)
1 Hour/2 Hours/4 Hours/8 Hours
(when the above check box is selected)
Offset Adjust the starting position for the
document scanning.
Unit:
For connection via SCSI/USB Connec-
tor:
ADF (Front), ADF (Back) (fi-6670/fi-
6770 only), Flat Bed (Flatbed type only)
For connection via VRS option:
ADF (Back), Flat Bed (fi-6770 only)
Main/Sub: -2 mm to 3 mm (in steps of
0.5 mm)
Main/Sub:
0 mm
Ye s Ye s
Vertical magnification
Adjustment
Adjust the magnification in the
feeding direction on the scanning
side specified for [Unit].
Unit: ADF, Flat Bed (Flatbed type only)
Setting range: -3.1 to 3.1% (in steps of
0.1%)
0% Yes Yes
PART NO. Default
PAxxxxx-Bxx1 Selected / 4 Hours
PAxxxxx-Bxx2 /Bxx3 /Bxx5 /Bxx7 Not selected
