This section describes how to change the ADF position.
1 Raise the Stacker.
2 Holding the handle, lift up the Document Cover.
3 Remove the ADF Lock Screws, and fix them to the Lock
Screw Storage Holes.
4 Gently close the Document Cover.
2.3 Changing the ADF Position (Flatbed Type Only)
Make sure that the ADF Lock Screws have been inserted
into the Lock Screw Storage Holes.
Lock Screw Storage Hole
ADF Lock Screw
To Next Page
