Fujitsu fi-6670 User Manual

Contents
16
Index
Appendix
Introduction
Glossary
Contents
TOP
Loading
Documents
Scan
Parameters
Various
Documents
Daily Care
Trouble-
shooting
Operational
Settings
Consumables
Scanner
Overview
Contents
How to Use This Manual ........................................ 2
Introduction ............................................................. 3
Regulatory Information ........................................... 6
Conventions ............................................................ 8
Precautions ........................................................... 10
Safety Information ................................................ 12
Chapter 1 Scanner Overview............................ 20
1.1 Features .............................................................21
Features ............................................................... 21
1.2 Scanner Parts and Their Functions .................22
fi-6670 (ADF Type)............................................... 22
fi-6770/fi-6750S (Flatbed Type)............................24
Model-Common Parts .......................................... 27
1.3 Functions of the Operator Panels ....................28
Operator Panel .....................................................28
Indications on the Function Number Display........30
1.4 Turning the Scanner ON and OFF ................... 31
Turning the Scanner ON ......................................31
Turning the Scanner OFF.....................................31
1.5 Power Save Mode ..............................................32
1.6 Basic Flows of Scanning Documents .............33
1.7 Image Scanning Application ............................ 36
1.8 Centralized Management of Scanners ............ 37
Chapter 2 Loading Documents......................... 38
2.1 Loading Documents on the ADF ...................... 39
2.2 ADF-Loaded Documents .................................. 42
Sizes..................................................................... 42
Paper Quality........................................................ 42
Maximum Document Loading Capacity................ 44
Area Not to be Perforated .................................... 44
Loading Documents with Tabs or Non-Rectangular
Documents ........................................................... 45
Multifeed Detection Conditions............................. 45
Limiting the Background Color Area..................... 46
Job Separation Sheet........................................... 47
2.3 Changing the ADF Position
(Flatbed Type Only) ........................................... 48
2.4 Loading Documents on the Flatbed
(Flatbed Type Only) ........................................... 50
Chapter 3 Scan Parameters.............................. 51
3.1 TWAIN Scanner Driver ...................................... 52
Resolution ............................................................ 52
Scan Type ............................................................ 52
Paper Size............................................................ 53
Image Mode ......................................................... 53
[Scan] Button........................................................ 53
[Preview] Button ................................................... 53

Fujitsu fi-6670 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	256
Input color depth	24 bit
Maximum scan size	279.4 x 431.8 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
Maximum duty cycle	450000 pages per month
Auto document feeder (ADF) input capacity	200 sheets
Bundled software	Adobe Acrobat Standard, Kofax VRS Professional + Bar Code, ScandAll PRO, QuickScan Pro
Power requirements	AC 100 - 240V, 50 / 60 Hz
Maximum scan area (ADF) (imperial)	11 x 17 \
Minimum scan area (Auto Document Feeder)	2 x 3 \
Power consumption (standby)	6 W
Power consumption (typical)	216 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	299.72 mm
Width	431.8 mm
Weight	17009.7 g
