3 Select the [Enable Multi Image] checkbox.
⇒ The [Multi Image] dialog box appears.
4 Select [Multi Image Output] under [Output mode].
5 Select the order to output multi-images under [Order (for
Multi Image Output)].
• Primary: Color/Grayscale
Secondary: Binary
First, a color or grayscale image is output, and then a black-
and-white image.
• Primary: Binary
Secondary: Color/Grayscale
First, a black-and-white image is output, and then a color or
grayscale image.
6 Under [Select Current Image Setting], select a side (if in
Duplex Scan mode).
7 In the [TWAIN Driver (32)] dialog box, click the [OK]
button.
⇒ Changes made are saved.
8 From ScandAll PRO, perform a scan.
For how to perform a scan, refer to "ScandAll PRO V2.0 User's
Guide".

Fujitsu fi-6670 Specifications

General

Film scanning	No
Color scanning	Yes
Grayscale levels	256
Input color depth	24 bit
Maximum scan size	279.4 x 431.8 mm
Scanner type	Sheet-fed scanner
Sensor type	CCD
Maximum duty cycle	450000 pages per month
Auto document feeder (ADF) input capacity	200 sheets
Bundled software	Adobe Acrobat Standard, Kofax VRS Professional + Bar Code, ScandAll PRO, QuickScan Pro
Power requirements	AC 100 - 240V, 50 / 60 Hz
Maximum scan area (ADF) (imperial)	11 x 17 \
Minimum scan area (Auto Document Feeder)	2 x 3 \
Power consumption (standby)	6 W
Power consumption (typical)	216 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	299.72 mm
Width	431.8 mm
Weight	17009.7 g
