Brake Roller
Lightly clean the Brake Roller along the grooves on the roller, taking
care not to scratch its surface.
When cleaning the Brake Roller, remove it from the scanner. For how to
remove the Brake Roller, refer to "6.3 Replacing the Brake Roller" (on
page 105).
Pick Rollers
Lightly clean the Pick Rollers along the grooves on the rollers, taking
care not to scratch their surface. Take particular care when cleaning
these rollers as black debris on them adversely affects the pickup perfor-
mance. For how to remove the Pick Rollers, refer to "6.2 Replacing the
Pick Rollers" (on page 103).
Plastic Rollers
Lightly clean the Plastic Rollers, taking care not to damage their surface.
Take particular care when cleaning these rollers as black debris on them
adversely affects the pickup performance. Be careful not to damage the
sponges attached around the middle of the rollers.
Roller without grooves Roller with grooves
