134
Chapter 6 Installing Internal Options
6.3 Installing the CPU
Up to two CPUs can be installed in this server by installing an optional CPU.
6.3.1 Installation Location of CPUs
The server comes equipped with one CPU in CPU socket 1. Install an optional CPU in CPU socket 2.
• Before installing/removing the CPU, turn off the server and all peripheral
devices. Also unplug all power cables from the server ("1.4.3 Turning Off the
Server" (p.32)).
Failure to do so may cause electric shock or device failure.
• Do not install any unauthorized third party optional CPU. Doing so may cause
failures.
• Do not use a CPU with a different frequency or cache size. In that case the
system will not start.
• The circuit boards and soldered parts of internal options are exposed and can
be damaged by static electricity.
Before handling them, first touch a metal part of the server to discharge static
electricity.
• Do not touch the circuitry on boards or soldered parts. Hold the metallic areas
or the edges of the circuit boards.
CPU socket 2
(installed as a standard feature)
[Front]
CPU socket 1
To Next Page
