Chapter 1 Overview
f Reset switch (RST)
Pressing this switch resets and restarts the system.
All data being used are lost by pressing the Reset switch. Make sure to save the data before
you reset.
g Maintenance switch ( )
This switch is used only by maintenance personnel. Do not touch this.
h Power switch ( )
Press this switch to turn the server on.
Do not turn the server off when the hard disk access LED is blinking.
Data in the hard disk may be damaged.
i Front maintenance LED ( )
This LED lights or blinks yellow when abnormality is detected in parts in the server.
If this LED lights or blinks, contact an office listed in the "Contact Information" of the "Start
Guide".
j Hard disk access LED ( )
This LED lights green when data is being written to or read from the hard disk. Also, this LED
lights when the CD/DVD drive is accessed to.
k Power LED ( )
It is lit depending on the power supply status of the server as follows.
l USB connector ( )
Connects peripheral equipment conforming to the USB standard (2.0 or 1.1).
m CD/DVD eject button
Push the button when inserting or ejecting CD/DVD.
Do not push the button when the CD/DVD access LED is on.
n CD/DVD access LED
Blinks when reading data from CD/DVD.
table: Power status
LED status Power status
Off The power does not supplied.
Amber Normal status (standby mode)
Green Normal status (operating mode)
NMI
