136
Chapter 6 Installing Internal Options
3 Remove the fan duct.
Lift and remove the fan duct.
4 Remove the dummy CPU.
5 Remove the socket protection cover by pulling the tab up.
[Front]
Fan duct
[Front]
Dummy CPU
Socket protection cover
Tab
