Fujitsu Primergy RX200 S4 - Page 167

167
PRIMERGY RX200 S4 User's Guide
4 Remove the dummy unit from the bay where an internal hard disk unit will be
installed.
Dummy units are installed in bays where no internal hard disk units are installed. Pressing the
tabs on both sides of the dummy unit inward, pull the unit out towards you slowly.
 Keep the removed dummy units for later use.
5 Install the internal hard disk unit in the server.
Insert the internal hard disk unit into the bottom of the bay with its handle lifted.
6 Hold down the handle of the internal hard disk unit until it clicks.
Tab
Handle
Handle
