241
PRIMERGY RX200 S4 User's Guide
*1:
The function can be enhanced by Remote Management Ctrl Upgrade kit (PG-RMCU2). For details, refer to "Appendix D
Remote Management Controller" (
p.257).
Supported OS
The following OSes are supported.
• Windows Server 2008 Standard (32-bit)
• Windows Server 2008 Enterprise (32-bit)
• Windows Server 2008 Standard (64-bit)
• Windows Server 2008 Enterprise (64-bit)
• Windows Server 2003, Standard Edition
• Windows Server 2003, Enterprise Edition
• Windows Server 2003, Standard x64 Edition
• Windows Server 2003, Enterprise x64 Edition
• Windows Server 2003 R2, Standard Edition
• Windows Server 2003 R2, Enterprise Edition
• Windows Server 2003 R2, Standard x64 Edition
• Windows Server 2003 R2, Enterprise x64 Edition
• Red Hat Enterprise Linux ES (v.4 for x86)
• Red Hat Enterprise Linux AS (v.4 for x86)
• Red Hat Enterprise Linux ES (v.4 for EM64T)
• Red Hat Enterprise Linux AS (v.4 for EM64T)
• Red Hat Enterprise Linux 5 (for x86)
• Red Hat Enterprise Linux 5 (for Intel64)
The latest information about the supported OS
For the latest information such as notes on supported OS not described in this manual, refer to the
Fujitsu PRIMERGY website (http://primergy.fujitsu.com).
External
I/O port
Video 1 (analog RGB DSUNB 15 pin)
Keyboard 1 (PS/2 mini DIN6 pin)
Mouse 1 (PS/2 mini DIN6 pin)
USB 1 (Dsub 9 pin)
Serial N/A
Parallel 4 (front × 2, rear × 2)
LAN 3 (Modular (RJ-45) 8 pin), one port is occupied for iRMC2 exclusive use
Keyboard and Mouse Optional
Power supply unit
Quantity Standard: 1, Max: 2 (Redundant power supply devices)
Power/
Connector
100-240VAC (50/60Hz)/bipolar ground type
Fan unit System fans: 6 (Redundant)
Internal clock precision ± 2 to 3 minutes/month
Power consumption 577W/2077 kJ/h
Weight Approx. 18.4kg (including the inner rails of the rack mount kit)
Dimension (W × D × H)
430 (482) × 730 (774) × 43.5 (mm) (1U)
( ): including protrusion
Noise 52dB
table: Server Specifications (SAS model)
Item Functions and Specifications
To Next Page
