Fujitsu SPARC Enterprise M3000 Service Manual

7-4 SPARC Enterprise M3000 Server Service Manual • March 2012
FIGURE 7-2 shows the explanation of DIMM information.
FIGURE 7-2 Explanation of DIMM Information
7.1.2 Memory Mounting Conditions
Memory mounting conditions are as follows:
■ A maximum of eight DIMMs can be mounted. They are mounted in units of four
DIMMs in each of group A and group B.
■ The DIMM capacity of group A must be equal to or greater than that of group B.
The DIMM capacity of group A must not be smaller than that of group B.
■ The DIMMs included in the same group must have the same capacity and same
rank.
MEM#0A Status:Normal;
+ Code:ce0000000000000001M3 93T2950EZA-CE6 4145-473b3c23;
+ Type:1A; Size:1 GB;
Memory slot No.
DIMM size
1: 1 GB
2: 2 GB
DIMM rank
A: 1 rank
B: 2 rank
