Fujitsu SPARC Enterprise M3000 Service Manual

13-4 SPARC Enterprise M3000 Server Service Manual • March 2012
13.2 Removing a Fan Unit
1. While pressing the latch (1 in FIGURE 13-2), lift the fan unit (2 in FIGURE 13-2).
2. Remove the fan unit from the server, and place it on a conductive mat.
FIGURE 13-2 Removing a Fan Unit
2
1
