Fujitsu SPARC Enterprise M3000 Service Manual

10-1
CHAPTER
10
Replacing the Hard Disk Drive
Backplane
This chapter explains how to replace the hard disk drive backplane.
■ Section 10.1, “Accessing the Hard Disk Drive Backplane” on page 10-2
■ Section 10.2, “Removing the Hard Disk Drive Backplane” on page 10-3
■ Section 10.3, “Mounting the Hard Disk Drive Backplane” on page 10-5
■ Section 10.4, “Reassembling the Server” on page 10-6
The hard disk drive backplane is a cold replacement component. The entire server
must be powered off and the power cords must be disconnected to replace the hard
disk drive backplane.
