8-4
SPARC Enterprise M3000 Server Service Manual
•
March 2012
8.2
Removing a PCIe Car
d
Note –
If a new PCIe card is to be instal
led
in an empty disk slot, r
emove the PCIe
slot cover first.
1.
Remove the one screw securing the PCIe card.
2.
Pull a PCIe card strai
ght up from the slot, and
then place it on a conductive
mat.
FIGURE
8-2
Removing a PCIe card
117
