Chapter 11 CD-RW/DVD-RW Drive Unit (DVDU) Replacement 11-3
11.1 Identifying the Type of CD-RW/DVD-
RW Drive Unit
There are two types of CD-RW/DVD-RW drive units: slot-loading type and tray-
loading type.
FIGURE 11-2 Types of CD-RW/DVD-RW Drive Unit
Note – The locations of the LED and button might vary depending on the servers.
Note – When you use the medium on the tray-loading type CD-RW/DVD-RW drive
unit, make sure that the center of the medium is secured to the clamp of the tray, and
then push the tray into the drive.
Location Number Component
1 Tray-loading CD-RW/DVD-RW drive unit
2 Slot-loading CD-RW/DVD-RW drive unit
