10-2 SPARC Enterprise M3000 Server Service Manual • March 2012
FIGURE 10-1 shows the location of the hard disk drive backplane.
FIGURE 10-1 Hard Disk Drive Backplane Location
10.1 Accessing the Hard Disk Drive
Backplane
Caution – There is a risk of electrical failure if the power cords are not
disconnected. All the power cords must be disconnected to completely cut the power
to the server.
Location Number Component
1 Hard disk drive backplane (HDDBP#0)
1
