6-4 SPARC Enterprise M3000 Server Service Manual • March 2012
FIGURE 6-2 indicates the locations of DIMMs, PCIe cards, and shutter unit.
FIGURE 6-2 Locations of DIMMs, PCIe Cards, and Shutter Unit
6.1 Accessing the Motherboard Unit
Caution – There is a risk of electrical failure if the power cords are not
disconnected. All the power cords must be disconnected to completely cut the power
to the server.
Location Number Component
1 Memory (DIMM)
2PCIe card
3 Shutter unit
1
2
3
