14-2 SPARC Enterprise M3000 Server Service Manual • March 2012
FIGURE 14-1 shows the location of the fan backplane.
FIGURE 14-1 Fan Backplane Location
14.1 Accessing the Fan Backplane
Caution – There is a risk of electrical failure if the power cords are not
disconnected. All the power cords must be disconnected to completely cut the power
to the server.
Location Number Component
1 Fan backplane (FANBP_B)
