3-2
SPARC Enterprise M3000 Server Service Manual
•
March 2012
2.
Remove the power cord clamp and disconnect the cable.
FIGURE
3-1
Power-off Method
3.2
Failur
e Diagnostic Method
When an err
or occurs, a message is displa
yed on the maintenance monitor in many
cases. Use the flowchart in
FIGURE
3-2
to find the correct methods for diagnosing
failures.
39
41
