C.5 Connection Diagram for Serial Cable
FIGURE C-1 Connection Diagram for Serial Cable
RJ45
D-sub 9pin
1 RTS 8 CTS
1 CD
2 DTR 6 DSR
7 DSR 4 DTR
3 TXD 2 RXD
4 GND 5 GND
5 GND
6 RXD 3 TXD
8 CTS 7 RTS
