Appendix E DC Power Supply Model E-5
E.3 Electrical Specifications
This section describes the electrical specifications of the DC power supply model.
Note – This is equivalent to TABLE B-7. When using the DC power supply model,
refer to the content described in this appendix.
TABLE E-2 Electrical Specifications
Item Specifications
Frequency of CPU
2.75 GHz/2.86 GHz
Input voltage
-48 Vdc -60 Vdc
Number of power cords
2 (one for each power supply unit)
Power cord length
5 m/16.4 ft
Redundancy
1 + 1 redundant configuration
Rated current
*
* In a redundant configuration, the rated current per cable is half the value shown in
TABLE E-2.
10.52 A 8.50 A
Maximum power
consumption
†
† This value applies to the full configuration.
505 W 510 W
Heat dissipation
†
1,723.1 BTU/hr
(1818 KJ/hr)
1,740.2 BTU/hr
(1836 KJ/hr)
