Chapter 2 Hardware Overview 2-17
2.5 Labels
This section explains the labels and the card affixed to the server.
Note – The information on the label might differ from that shown on the affixed
labels.
■ The model number, serial number, and hardware version, all of which are
required for maintenance and management, are shown on the system faceplate
label.
■ The standards label is affixed close to the system faceplate label and shows the
approval standards.
■ Safety: NRTL/C
■ Radio wave: VCCI-A, FCC-A, DOC-A, MIC
■ Safety and radio wave: CE
A label-affixed card that can be inserted or extracted is provided near the power
supply unit at the right side at the rear of the server (see
TABLE 2-6). The card should
be inserted in such a way that the standards label faces the outside of the server and
the system faceplate label faces the inside of the server.
