5-4 SPARC Enterprise M3000 Server Service Manual • March 2012
5.2.2 Attaching the Top Cover
1. Align the top cover.
2. Tighten the three screws at the top rear of the server to secure the top cover in
the predetermined position.
3. Push the server back into the equipment rack.
For details, see "Section 5.1.2, “Sliding the Server into the Equipment Rack” on
page 5-3.
5.3 Removing and Attaching the Air Duct
5.3.1 Removing the Air Duct
Caution – Before the air duct is removed, the top cover must be removed. For
details, see Section 5.2, “Removing and Attaching the Top Cover” on page 5-3.
■ Hold the air duct and lift it upwards.
