1-2 SPARC Enterprise M3000 Server Service Manual • March 2012
FIGURE 1-1 Wrist Strap Connection Destination
Caution – Do not connect the wrist strap cable to the conductive mat. Connect it
directly to the server.
The wrist strap and FRU must have the same level of potential.
■ Hard disk drive or fan unit:
Connect to one of two thumbscrews
on the front of the server.
■ FRU* other than hard disk drive and fan unit
Connect to either upper right on the front or upper left
on the rear of the server.
* FRU: Field Replaceable Unit
